Description
Suits below vehicles
X5 (E53) 3.0 d 2001-04 - 2003-09
NOTE: This does not suit the M57N or M57N2. This is for the original Narrow Block M57 ONLY
2-LOCH
Please check how many holes are in the gasket you have removed and match for the same thickness gasket, Refer to our second image as an example which is a 3-LOCH.
0-LOCH (no hole)
1-LOCH (1 hole)
2-LOCH (2 holes)
3-LOCH (3 holes)
----------------------
OE PN 11122248983
Elring PN 157.420
Dimensions and size
| Diameter | 85.3 | mm |
| Thickness | 1.55 | mm |
Specifications
| Installed thickness | 1.55 mm |
| Notches/Holes Number | 2 |
| Piston Protrusion from | 0.93 mm |
| Piston Protrusion to | 1.03 mm |
| Gasket Design | Multilayer Steel (MLS) |
| Number of layers | 3 |
| Additionally required articles | 802.801 article numbers |
Shipping Details
| Weight | 0.891 Kg |
| Weight Volumetric | 1.782 Kg |
| Customs Code | 848410 |
| Country of Origin | Taiwan |
