Gigglepin Extended Air Operated Free Spool Drum 8274+76mm

GigglepinSKU: G11001/2

Sale price$1,225.50


This pneumatic FreeSpool drum is a direct replacement for the drum on a standard Warn 8274/8074 (of any age).

This Drum is a +76 Widened Drum, you will require a custom bullbar/winch cradle for this Drum

We have completely redesigned our FreeSpool drum to be stronger, lighter and easier to use. It now features a reduced diameter drum and a stronger engagement system. Fitted with large roller bearings, 8mm drum plates, rope retainer loop and housing seal.

Also Includes the Electrical Activation Kit
Kit Includes
  Air Solenoid,
  Y Piece kit to mount your solenoid directly to an ARB compressor,
  On/Off electrical switch,
  Red 'Fighter Pilot' style switch cover,
  4M 6mm air pipe,
  2 x High Quality 1/8BSP Breather Elbows,
  Roll of PTFE tape,
 Wiring diagram for solenoid connections.

Drum Features -

  • NEW stronger engagement system with smoother free-spool action
  • Sealed drum bearing on the free end with aluminum bearing support
  • 8mm thick Drum end plates to reduce flex.
  • Drum end plates spaced away from lower housing so if either do flex the drum continues to operate.
  • Stainless steel bearing supports to stop corrosion
  • Reduced diameter drum available in two lengths, short and long (+76mm)
  • IMPROVED EN36 case hardened dog engagement technology for total reliability
  • Large free end sealed bearing & adapter/retention ring for smooth operation
  • PTFE support washer for perfect sealing and smoother operation
  • Gigglepin rope retention system
  • Supplied with Nitrile drum seal
  • Tough Black Nylon Coating
  • Supplied with GP Seal Lube (G10018)
  • Supplied with fitting guide
