QIKAZZ Fan Cooling Upgrade + Wide Radiator + Thermostat + Hoses for Nissan Patrol GU TD42

Save $150.00
QIKAZZ 4x4 & CampingSKU: EWGUUltimate-+WideRad+Thermo

Price:
Sale price$1,099.00 Regular price$1,249.00

Description

NOTE: This combo suits the GU TD42T (NON Factory Intercooled) that are fitted with the Wide Radiator. Click here if you require the TD42Ti Narrow Radiator combo.

Included in this package is

  • QIKAZZ Ultimate Fan Upgrade Kit
  • Adrad Alloy/Plastic Standard Wide OEM Replacement Radiator
  • Mackay or Gates Top and Bottom Radiator Hoses
  • Tridon Radiator Cap
  • Dayco DT79A Thermostat
  • Genuine Nissan Thermostat Gasket

Well you have all been waiting for this. This IS the ultimate in keeping your TD42 Cool, designed and tested here in Australia using only the highest quality parts.

If you want to keep your GU TD42 cool, look no further, perfect for these long hill climbs, or when towing your camper/caravan.

The Fan suits all GU TD42 Engines

This fan and hub is much larger than any Nissan fan and out performs all of the Nissan units by up to and over 10 deg (based on averages after testing on many vehicles with varying fan/hub configurations including the G35 Fans)

The adaptor has been designed and engineered from the ground up with a true centre spigot to keep it all perfectly lined up and spinning true.

The fan is a Genuine Mitsubishi Fan, NOT an Aftermarket cheap quality unit that will over flex and hit your shroud or radiator. (yes we could give you a cheap fan, but we don't want to take this risk, do you?)

The Viscous Hub is the Highest quality Aftermarket unit, manufactured by a company with over 45 locations in almost 20 countries, so rest assured your getting a quality product,  again - this is no cheap Chinese product.

Forget adding oil to your current setup, that only makes the fan engage all the time, it drags power away from the engine and still doesn't help anywhere near enough, even with the G35 fan. Trust us, we have tried. :) With this setup you can really hear when the fan engages and disengages so you know its working well.

This kit also includes a Dayco D79A Thermostat and a Genuine Nissan Thermostat housing gasket. The Dayco D79A Thermostat fully opens slightly later than the standard Nissan Thermostat but it also blocks the bypass hole, which stops the constant hot water circulating and allows the thermostat to properly work. From the testing we have found it gives the engine a more consistent water temp at the same time as allowing the radiator to cool the water more efficiently .

Also included in this kit is the Adrad Alloy/Plastic Radiator at an affordable price these can be included in the kit without sacrificing quality. Adrad is a trusted brand in the Radiator Industry.

Mackay Top and Bottom Radiator Hoses as well as a new Radiator Cap are also in the package.



NOTE: The Fan will only work with a stock size radiator, IE 2 core on GQ and 1 core on GU, any thicker upgraded radiators like 3 core on  GQ or 2 core on GU or custom made larger radiators may cause this fan to foul on the shroud or the radiator itself.  We will not be liable if you damage your shroud or radiator after fitting this fan and not checking your fan clearances are safe.

If you have a GU ZD30 to TD42 converion done on your Patrol and you have kept the ZD30 Automatic Crossmember, you will not have the correct clearance to run this fan.

NOTE : If you are in a regional area please contact us for a freight quote, Free freight includes all major capital cities.
